DNA Micro Detection
-
Sample Volume
0.5 μL~2 μL, suggest 2 μL
-
Optical Path
0.02 mm, 0.03 mm, 0.05 mm, 0.1 mm, 0.2 mm, 1 mm
-
Light Source / Lifespan
Xenon flash lamp / Xenon flash lamp>10^9
-
Detector
2048-element linear CMOS array
-
Wavelength Range
190~1100 nm
-
Wavelength Accuracy
±1 nm
-
Wavelength Resolution
≤1.6 nm (FWHM@Hg 253.652 nm)
-
Absorbance Repeatability
0.002 Abs
-
Absorbance Accuracy
±1% (7.332 Abs @260 nm)
-
Absorbance Range
0.04~550 (@260 nm, equivalent to a 10 mm optical path)
-
Nucleic Acid Detection Range
2 ng/μL dsDNA~27500 ng/μL dsDNA
-
Test Time
<8 s
-
PVF-1 Detection
-
Absorbance Repeatability
Typical values: 0.01 A (1 mm optical path) or 1% CV, taking the larger one (10 separate measurements of SD)
-
Absorbance Accuracy
3% (0.97 A @302 nm, 25 °C)
-
OD600 Detection
-
Absorbance Range
0~4.000 Abs
-
Absorbance Stability
[0,3)≤0.5%, [3,4)≤2%
-
Absorbance Repeatability
[0,3)≤0.5%, [3,4)≤2%
-
Absorbance Accuracy
[0,2)≤0.005 A, [2,3)≤1%, [3,4)≤2%
-
Fluorescence Detection
-
Fluorescence Light
Blue, red (optional, default is bule)
-
Linearity
R^2>0.995
-
Linear Range
<1.5%
-
Sensitivity (Limit of Detection)
<1.5%
-
Others
-
Dimension (W×D×H)
260×333×346 mm
-
Input Voltage
DC24 V 2 A
-
Power
25 W
-
Weight
5.7 kg
-
Data Export
USB, Label Printer, Networks
-
Networking
Wi-Fi and Ethernet
